Bentley Service & Repair Manual - E83 X3 BMW (2004-2010)

The most comprehensive service manual available for your 2004-2010 X3 sport activity vehicle (SAV) there is. Hardcover, 1040 pages and over 1884 photos, illustrations and diagrams. Covers all model E83 chassis X3 including 2004, 2005, 2006, 2007, 2008, 2009, 2010 - X3 2.5i, 3.0i, 3.0si, xDrive3.0i

Models and engines:
2.5i M54 engine, 6-cylinder 2.5 liter
3.0i M54 engine, 6-cylinder 3.0 liter
3.0i N52 engine, 6-cylinder 3.0 liter

Transmissions (remove, install, external service):
Manual ZF GS6-37BZ (6-speed)
Automatic GM A5S390R (5-speed)
Automatic GM GA6L45R (6-speed)

  • Maintenance procedures from changing the xDrive fluids to replacing the cabin microfilter. This manual tells you what to do and how and when to do it.
  • Manual and automatic transmission fluid service, front and rear differential service, including xDrive transfer case troubleshooting.
  • Step-by-step variable camshaft timing (VANOS) service.
  • Cylinder head cover gasket and crankshaft seal replacement.
  • Cooling system, thermostat and radiator service, including system bleeding using the electric coolant pump on N52 engines.
  • Fuel injection and ignition system diagrams and explanations.
  • Information on advanced technical features such as VANOS, Valvetronic, xDrive, and DSC (dynamic stability control).
  • Suspension repair procedures.
  • Brakes, steering and ABS troubleshooting and repair.
  • Heating and air-conditioning repair, including A/C component replacement.
  • Body and hood repairs and adjustments.
  • Electrical system service, with an easy-to-use illustrated component locator section.
  • Comprehensive wiring schematics, including fuses and grounds.
  • BMW OBD II diagnostic trouble codes, SAE-defined OBD II P-codes, as well as basic scan tool operation.
  • BMW factory tolerances, wear limits, adjustments and tightening torques.

  • This item fits the following BMWs:
    2004-2010 E83 BMW X3 2.5i X3 3.0i X3 3.0si
    T#: 211231 | Part#: TMS211231
    99.95 $99.95
    Free Shipping
    Ships on Apr 22, 2019
