Cylinder Head and VANOS Tools

When servicing your vehicle's VANOS system, get the job done easier with this socket specifically designed for the removal of the VANOS solenoid.

Features:

• 85mm from end to end
• 1/2" drive
• 32mm with a depth of 70mm.

Schwaben BMW Vanos Adjustment - Wrench is essential for the precise installation of a new or rebuilt VANOS unit on your BMW. This specialized tool ensures that the VANOS system is correctly adjusted, which can significantly impact your vehicle's performance and overall operation once reassembled. Proper VANOS adjustment is crucial for maintaining optimal engine timing and efficiency.

• Precision Tool: Designed specifically for BMW VANOS unit adjustments, ensuring accurate installation.
• Improved Performance: Helps maintain optimal engine timing and efficiency, leading to better vehicle performance.
• Essential for Rebuilds: Critical for the installation of new or rebuilt VANOS units, preventing potential issues during reassembly.
• Durable Construction: Built to last, providing reliable performance through multiple uses.

This gauge ensures that the inlet and exhaust cams are aligned perfectly. Make sure the edges are on the correct sides of the cylinder head before using.

Includes two alignment pin's which is ideal for inspection and servicing the motor with the timing chain still attached. If you are going to be removing the timing chain for service, you will need to lock both cams.

The Ultimate kit includes every thing the standard kit does along with, a second alignment bridge, flywheel lock pin, VANOS alignment tools. and 4 bolt crank socket.

This tool fits all S54 powered BMW, including:
2001-2006 E46 BMW M3
2001-2002 E36/7 BMW Z3M Coupe Z3M Roadster
2006-2008 E85/6 BMW Z4M Coupe Z4M Roadster


The Schwaben Piston Ring Filer is a vital tool for obtaining the precise end gap necessary for optimal piston ring performance.

This filer allows you to swiftly and accurately file piston rings to exact measurements, enhancing your engine’s efficiency and lifespan. By simply positioning the piston ring and turning the handle, you can easily rotate the abrasive wheel for a smooth and effective filing process.

**Note:** For the Schwaben Universal Piston Ring Compressor, check out T25805755!

Key Features:

• Optimize Performance: Achieve the perfect end gap crucial for top engine efficiency.
• Quick and Precise: File rings to exact specifications with ease.
• Easy Operation: Position the piston ring and turn the handle to effortlessly rotate the abrasive wheel.
• Enhanced Engine Longevity: Accurate end gaps contribute to longer engine life and better performance.

Instructions:

1. Position the Ring: Place the piston ring on the outer edge against the stop and align the ends squarely against the grinding wheel. Apply light, even pressure against the wheel to prevent grinding too large a gap.
2. Operate the Tool: Turn the handle so the grinding wheel turns towards the inside edge of the ring (counter-clockwise when viewed from the handle side of the tool).
3. Exercise Caution: This is a diamond grinding wheel. It cuts fast!

Checking Piston Ring Gap:

1. Deburr the Ring Ends: Carefully remove any burrs on the ring ends before placing the ring in the bore. A light touch with a fine abrasive stone works well.
2. Clean the Rings: Thoroughly clean the rings with lacquer thinner or acetone, as the paint coating from the factory may occasionally scratch the cylinder bore. Always wear gloves during this process.
3. Position the Ring in the Cylinder: Place the ring squarely in the cylinder bore, about 1" down from the deck surface. An upside-down flat-top piston will help you properly square the ring.
4. Measure the End Gap: Use a feeler gauge to measure the ring's end gap. Apply light grinding pressure and check frequently to avoid making the end gap too large.

WARNING: This product contains chemicals known to the state of California to cause cancer, birth defects, and/or reproductive harm. See above warning label as well as http://www.p65warnings.ca.gov for further information on Proposition 65 warnings.

Achieve precise timing adjustments on your BMW N63TU and S63TU engines with the Schwaben N63TU/S63TU Timing Tool Set. Specifically designed for models from 2012 onwards, this all-inclusive kit is essential for accurately setting up camshaft and crankshaft timing.

Each tool is engineered to the exact standards needed for these engines, ensuring dependable and efficient performance. Conveniently packed in a blow-molded case, this set offers easy storage and portability, making it an ideal addition to any professional or home mechanic's collection.

Moreover, with our LIFETIME REPLACEMENT program, you can have peace of mind knowing that any tool from this set will be replaced if it ever fails – we've got you covered!

Replaces BMW OEM Part Numbers :

• 2249117
• 2249140
• 2249144
• 2249159
• 2249162
• 118570
• 119190

WARNING: This product contains chemicals known to the state of California to cause cancer, birth defects, and/or reproductive harm. See above warning label as well as http://www.p65warnings.ca.gov for further information on Proposition 65 warnings.

Looking to update your old torque wrenches? The Schwaben 3/8" Drive Digital Torque Wrench is your answer.

This digital torque wrench uses an easy-to-read display to show torque amounts and settings, features a push button release, reversible 3/8" drive, 45 tooth ratchet head, and a comfortable no-slip grip and adjustment wheel.

Specifications:

• Setting Range: 45-220 ft lbs (60-300 Nm)
• Display Units: ft-lbs, N-m, Inch-lbs, cm-kg2, and m-kg
• Size: 22" (550mm) length for easy leverage
• Accuracy: +- 3%
• Include blow molded holding case
• Requires one 3V CR2030 battery (included)
