Blow Off Valves & Diverter Valves for BMW X Series F25 (2011+)

GFB’s DV+ solution couldn’t be simpler - keep what works and replace what doesn’t.

Worldwide Patent and Design Patent Pending

• Retains the factory solenoid coil for seamless integration
• Replaces plastic valve parts with metal for reliability and strength on chipped engines
• Direct-fit replacement with GFB’s TMS benefits
• Exclusive “pilot-actuated” valve mechanism for rapid response at high boost

GFB expands the DV+ range with a direct-fit solution for the weak factory diverter valve used on many European vehicles.

The solenoid coil itself from the factory-fitted valve is great (the ECU opens it faster than any pneumatic valve so why replace it?), but the weak point however is the valve mechanism itself. So GFB’s DV+ solves this problem by replacing just the valve parts with an anodised billet aluminium housing fitted with a brass piston machined to exacting tolerances.

The end result is sharper throttle response, lightning-fast valve actuation, and it will hold as much boost as you can throw at it. Read all about the DV+ story on the next page.

Other manufacturers’ products involve replacing the entire system with a traditional pneumatic valve, requiring long vacuum hose runs, additional parts for tapping into the intake manifold vacuum, plus either a different solenoid valve to actuate the pneumatic valve or a ballast resistor to plug into the OE wiring loom. All these additional items result in a product that is slower, less responsive, more expensive and takes much longer to install.

GFB’s DV+ solution on the other hand is more responsive, less expensive, easier to install, and doesn’t cause compressor surge/turbo flutter. Oh, and it doesn’t require different springs or frequent re-builds.

Many late-model European cars use ECU controlled solenoid-type diverter valves. This is a good concept because the valve can react very quickly and it only opens when it needs to.

However, there are some problems with these valves. There are typically two types of solenoid-actuated diverter valves found standard on VAG and European cars, both of which have their shortcomings.

Common OE Problem #1
The diaphragm types are commonly known to rupture, especially when boost and temperature are increased as a result of chip tuning.

Common OE Problem #2
The plastic piston-type leaks far more than most people realise (by design, not from wear), and doesn’t always close after a high-boost gear shift.

Additionally, in both cases, the solenoid on the OE diverter is directly connected to the valve mechanism, which is not ideal because neither it nor the return spring are strong enough to open and close the valve reliably at high boost.

With problems like this, you can see why other aftermarket manufacturers assume the best solution is to replace the factory diverter entirely. Unfortunately though, whilst their replacement kits might be stronger than the factory diverter, their slower response speed and lower flow do not justify the extra cost and complexity - more of a compromise than a solution.

GFB has taken a different approach to deliver a complete solution that solves existing problems and improves performance, without compromise or a hefty price tag.

The DV+ addresses the factory valve problems with a very simple and elegant solution. Keeping the factory solenoid retains all the benefits of the stock system, and replacing the valve parts with indestructable metal components ensures strength and reliability no matter how much boost you run.

That's not all. Rather than using the solenoid to directly actuate the valve, we’ve introduced a unique “pilot-actuation” system. This means the solenoid controls the air pressure that is used to open and close the piston, so it doesn't matter how much boost you push through it, the DV+ will open and close reliably without ever exceeding the solenoid’s capability.

This feature also improves on the factory system by opening the valve progressively in response to boost pressure, so it only opens as much as required to get the job done (the factory valve simply opens and shuts, it cannot partially open if boost pressure is low), resulting in better throttle response.

The Turbosmart BOV Kompact EM Dual Port - BMW N20/N26 (VR23) offers an advanced blow-off valve solution designed specifically for BMW’s N20 and N26 engines. Engineered with premium materials, this bolt-on unit provides an ideal balance of performance and durability. By improving turbo response and boosting control, it maximizes power efficiency and prevents compressor surge, enhancing the life of your turbocharger system. Turner Motorsport offers this product as a direct replacement with easy installation and seamless compatibility for BMW enthusiasts looking to optimize performance.

• Dual Port Venting: Allows for a combination of recirculation and vent-to-atmosphere options, enhancing flexibility.
• Compact Design: Precision-engineered to fit neatly into tight engine bays while delivering maximum efficiency.
• Plug-and-Play Installation: Designed as a direct OEM replacement, making installation straightforward.
• Improved Throttle Response: Reduces lag and improves acceleration, creating a smoother driving experience.
• Quality Construction: Made from high-grade aluminum alloy for durability and performance.

Upgrade your BMW’s turbo system with the Turbosmart BOV Kompact EM Dual Port, the trusted solution for performance enthusiasts.

Turbosmart GenV Raceport BOV (Fits competitors 50mm / female style flange. No weld flange included)

The Race Port is renowned for its exceptional compactness and lightweight design tailored for turbocharged competition-level engines. With its innovative collar design and internal flow structures, this BOV stands out as 50% lighter and 25% smaller than competing models, yet it boasts an impressive flow rate of 330 CFM, making it the market's top-performing BOV in its category.

Fits Chargepipes With Tial/Turbosmart Flange

The diverter valve is responsible for redirecting boost away from the intake when it's not needed. Other cars use a blow-off valve to vent the pressurized air into the atmosphere (the whoosh sound commonly heard on turbo engines) but BMW and other makers use a diverter valve to keep the air circulating through the intake for emissions purposes. A failing diverter valve will lead to a boost leak as turbocharged air leaks past the seals instead of going into the engine when you want it. This is a minor issue on stock engines but a bigger issue on tuned or heavily modded engines (those will use an aluminum diverter valve instead of the stock plastic). The factory diverter valve is plastic which is prone to cracking and electric which will fail without warning. This is a direct replacement diverter valve for cars with the N55 and S63 (X5M/X6M) engines.

N55 takes 1 diverter valve.
S63 takes 2 diverter valves (1 per turbo).

This item fits the following BMW Chassis:
E70 X5M,E71 X6M,E70 X5 X5,E71 X6,E82,E90,E92,E93,F06,F10,F12,F13,F15,F16,F22,F25 X3,F26 X4 X4,F30,F32,F33,F34,F36
S63 engine applies to X5M/X6M only. Fxx M5/M6 uses S63TU engine and does not use a diverter valve at all.
