E36 M3 96-99 Stage 4 Turner Motorsport Performance Package

Mfg Part #
Turner Part #
Ships on Sep 18, 2018
Does this fit my vehicle?
For accurate results, specify your model below.

Product Details

1996-99 E36 M3 Stage 4 Performance Package
Peak Power Gain: +24whp / +25wft-lbs
Rev limit: 7000
Octane: 91 or higher

Stage 4 Performance Package includes:
aFe Euro Cold Air Intake (oiled cotton filter, heat shield, HFM adatper, and intake tube)
Porsche 911 3.5" HFM (Bosch #0 280 217 803 or 0 280 217 809)
Turner HFM wiring harness adapter and bracket
"24lb" fuel injectors
Schrick performance camshafts (264/256 degree)
TMS Shorty headers
TMS Shark Injector performance software
hardware, install instructions

The Stage 4 Package takes the intake/cam Package from Stage 3 and adds our celebrated 'Shorty' headers. These headers are a bolt-on to the engine and stock catalytic converters on the E36 M3. Other headers have to be used as a system with additional exhaust sections required for fitment. Our headers bolt straight on using factory gaskets and hardware and make an excellent mid-range improvement in power.

The TMS Shorty Headers are manufactured in the USA and are CARB-certified. These headers are not cheap, knock-off pieces. They are 100% T-304 stainless steel with ceramic coating. The coating and the stainless steel are crucial for the efficient flow of exhaust gas through the header. Other versions use only mild steel. We have also taken the extra step of adding ports for the secondary air system, allowing your car to remain emissions-compliant.

As with Stage 3, this Package includes the aFe Euro Cold-Air Intake, 24lb fuel injectors, Schrick performance camshafts, Porsche HFM, and special Stage 4 TMS Shark Injector software. This is a further refinement to Stage 3 - boosting top end horsepower while still making more torque down low. Peak power and torque is increased over Stage 3 with significant torque improvements from 5000 RPM.

Related Upgrades -
Underdrive Power Pulley Kit - Underdriving means each component is moving slower which requires less power. The saved horsepower is put back to the engine where it transfers to power at the wheels. Power gains are typically 10hp at the wheels.
Exhaust - Borla or Corsa cat-back muffler for more performance, lighter weight, and a more-aggressive sound. Expect a gain of 5whp with either of these exhausts.


This item fits the following BMWs:
1996-1999 E36 M3 (manual transmission)

Kit Contents

Description Qty
Mass Air Flow Meter 1
aFe Intake Kit - E36 323/325/328/M3 - Stage 2 Pro5R 1
E36 M3 Euro HFM Adapter (to Stock Throttle Body Boot) 1
Bosch 24 lb Fuel Injector 6
E36 M3, MZ3 Schrick 256 Exhaust Camshaft with 10.6mm Lift 1
E36 M3, MZ3 Schrick 264 Intake Camshaft - 11.2mm Lift 1
Gasket Kit For Shorty Headers For 96-99 Cars 1
Turner Porsche 3.5" HFM Wiring Harness Adapter 1
Stage 4 Shark Injector: HFM, 24lb injectors, Schrick cams, Headers 1

This Part Fits the Following BMWs

Make Model Submodel Engine
BMW E36 M3 S52 3.2L
