Oiling System for BMW 6 Series E24 (1977-1989)

When we designed this catch we wanted to have the most function options available, the best separation method, and the easiest to service. The Turner engineered catch cans offer a pre-setup design based ion desired flow direction, however this does not limit you to this flow. The inner baffle orientation can be easily adjusted to flow in both directions in case you decide to move this catch can to a different vehicle. A 4 chamber system  baffle system inside the catch can was engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can. Having a closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation.

Our catch can was also designed with the idea that the cans fill level can easily be checked with a top mounted dipstick and an optional use bottom drain hole. The drain system comes complete with a valve and hose to be mounted at a lower area of the vehicle so when you're doing an oil change you can drain the catch can.

Features:

• 6061-T6 billet machined body, anodized black for lasting protection and appearance
• Strategically positioned 4 chamber baffle system maximizes oil / air separation
• Knurled and black anodized oil dipstick makes inspecting oil volume of reservoir clean and simple
• Sealed with a pre-installed viton O-Ring
• Includes 2.5mm allen key to remove baffle plates for cleaning
• Engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can
• Closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation
• Optional use drain hole - drain kit included!
• Universal mounting kit

Elevate your custom installation with the ECS -10AN O-Ring Boss fitting, a crucial component that connects your ECS Tuning Catch Can to a 3/4" ID hose. This fitting simplifies your plumbing setup, ensuring a seamless solution.

Featuring a pre-installed Viton O-ring, this fitting is engineered for excellence, providing a leak-proof seal that resists the effects of oil and fuel exposure, guaranteeing long-term durability.

The 3/4" nipple is thoughtfully designed with barbs to secure hose position effectively, minimizing the risk of hose disconnection. Keep in mind that clamps and hoses are available for separate purchase. These fittings are sold individually, with most installations requiring a pair of them.

Genuine BMW Set Oil-Filter Element
This item fits the following BMW Chassis:
E12, E28, E34, E24, E23, E32

Fits BMW Engines including:
M30,S38

Replacement engine oil filler cap with seal (Original BMW brand). Oil caps can go bad.... If the cap is not sealing to the valve cover it will result in a vacuum leak (poor idle, rough running, etc). It also helps regulate pressure in the cylinder head. While there is no life expectency, there's no downside to replacing it every few years. This is a Genuine BMW part.

When doing any sort of repair or maintenance there is no replacement for genuine factory parts. Turner Motorsport carries the Genuine BMW brand with pride and has the parts you need to complete your next project with confidence.

This item fits the following BMWs:
1967-1976 2002 BMW 2002 2002tii
1977-1983 E21 BMW 320i 323i
1984-1985 E30 BMW 318i
1984-1991 E30 BMW 325e 325es 325i 325is 325ic 325ix M3
1982-1988 E28 BMW 528e 533i 535i 535is M5
1989-1990 E34 BMW 525i
1989-1993 E34 BMW 535i M5
1977-1989 E24 BMW 633csi 635csi M6
1977-1987 E23 BMW 733i 735i
1988-1994 E32 BMW 735i 735il

Modern emission regulations require a closed PCV/Breather system for cleaner operation. However, inefficient oil particle capture can lead to excessive oil vapor ingestion, causing carbon buildup, reduced performance, and fuel economy. ECS Tuning's updated ECS Baffled Oil Catch Can, now with an easy-to-empty 1/4" drain fitting, is engineered to collect toxic blow-by gases, minimize carbon deposits, and reduce oil contamination within engine oil. Recirculating oil vapor ensures emissions compliance without venting to the atmosphere.

• Key Features:
• Highly Efficient Oil Separator: Strategically positioned 4 chamber baffle system maximizes oil/air separation and minimizes oil droplets in the intake tract.
• Integrated Dipstick: Knurled and black anodized oil dipstick simplifies oil volume inspection.
• Reservoir: Available in 6oz or 8oz capacity with a 1/4" NPT drain plug fitting.
• Serviceable: Easily removable baffle plates and drain plug for cleaning.
• Easy/Customizable Installation: Combine with the ECS Universal Bracket Kit for simplified installation and adjustable mounting locations.
• Leak-Free Fittings: Machined -10AN ORB (O-Ring Boss) fittings available for secure connections (fittings sold separately).

• Ensures tight seals on power steering and oil lines
• Maintains proper fluid containment
• Prevents leaks for enhanced performance and reliability
