Please ensure your correct model is selected
Introducing our newest upgrade for your E36: a full billet aluminum valve cover engineered to eliminate factory and aftermarket valve cover issues. If you're familiar with our new Turner Motorsport products for 2023 and 2024 you can tell that our engineering team at Turner has a focus on older chassis, especially the E36.
Our valve cover is designed to fit some of the best engines BMW ever came out with, single vanos M50/M52 and S50/S52. Not only are these great motors in general and deserve an upgraded valve cover but they are also prime for boosting. When adding boosting you will be introducing heat which can wreak havoc on your ignition system and make your factory valve cover extremely prone to failure.
The reality of the M5x/S5x motors is that the plastic valve covers are sub-par and the magnesium versions are no longer available from BMW and even those can even warp. You can end up replacing your valve cover time and time again dealing with issues if you prefer but the option is here for you. The last valve cover you buy for your E36.
Our engineers designed this valve cover with experience and personal passion that offers a plethora of benefits for your M5x/S5x motor. Whether you plan to cherish your E36 for years to come or envision a turbocharger upgrade, our valve cover is the ultimate solution. It boasts rugged durability and brilliant aesthetics, ensuring it's a perfect fit for any enthusiast.
Featuring full 6061 billet construction and a type-3 hard coat finish, our valve cover is built to endure extreme conditions and rigorous use. Whether you opt to retain your factory PCV setup or upgrade to a catch can for racing purposes, the cover provides dedicated, direct-fit ports for both configurations.
The base kit includes all the necessary components for a seamless installation. Additionally, the description provides part numbers for optional replacements and add-ons, ensuring you have everything you need to complete your install.
Features:
Integrated -10AN ORB ports for a catch can setup to keep your intake free from oil in racing applications
Compatible with factory M5x/S5x ignition coil packs
Compatible with Red Top "Smart Coils" (Audi R8) for standalone ECU applications
Stainless steel coil pack heat shield for enhanced protection in factory and top mount turbocharger applications
Compatible with factory oil cap
Modular heatshield with bendable tab to accommodate 96-99 coil harness that crosses over the top of the exhaust manifold
Online instructions included for PCV, heatshield and coil pack installation
Benefits:
Leak-free - Never deal with a warped valve cover again thanks to the full billet aluminum construction
Retains all factory PCV functions
Protected ignition coils and wiring
Superior heat resistance - Will not melt like plastic replacement valve covers
Durable and clean anodized coating able to withstand excessive engine and exhaust temperatures
Optimized oil path for vanos/timing chain lubrication
Design:
Full 6061-T6 Billet Aluminum
Type 3 black hard coat for increased durability and thermal capacity
Compatible with all Single Vanos M5x/S5x engines
Heat shield with black anodized Turner back plate for a clean and durable finish
Designed to utilize M50/S50 valve cover gasket - fits all M50, M52, S50, S52
Kit options:
The base kit includes:
Billet Valve Cover
Heat Shield, PCV Adapter - QTY 1
-10AN ORB Block-Off Fittings - QTY 2
M50/S50 Valve Cover Gasket Set
Valve Cover Securing Hardware Grommets - QTY 15
Ignition Coil Install Hardware (M6x1, 25mm length) - QTY 12
Heat Shield Install Hardware (M6x1, 12mm length) - QTY 4
Optional Ignition Coils
PCV options:
There are different PCV connections based on year splits for M5x/S5x motors. If you have a damaged or worn-out PCV component please reference the replacement component that matches your motor.
(1995 Only) Valve cover breather connector - P# 11151703710
(1996-1999) Replacement oil separator hose - P# 11151703775
Looking for catch can and or AN lines and fittings?
Right angle catch can feed/return lines - T#26493912
Feed/Return line separator - T#26493913
Universal catch can kit with mounting - T#398786
If there is a large amount of oil on the sides of the engine or if you can smell burning oil, chances are it's a bad valve cover gasket. The gasket fails and allows oil to seep down onto the side of the engine and other parts causing a mess and reducing the amount of oil in your engine. This replacement gasket from Elring is perfect to prevent any further oil leaks.
Includes the following Seals:
Elring is one of the biggest OEM names in the manufacturing of high quality gaskets that are available for very affordable prices. Elring has supplied many automotive names for years with the gaskets that seal your car's components from day 1 so you can rest assured that these components will last for a long time to come!
This item fits the following BMWs:
M50 2.5L
S50 3.0L
The gasket on this valley pan cover can fail and cause a coolant leak. Sometimes you may notice coolant leaking from the transmission bell housing. This fits E39 540i E38 740i E32 740i E34 540i X5 4.4i 4.6is E31 840i 840ci.
When doing any sort of repair or maintenance there is no replacement for genuine factory parts. Turner Motorsport carries the Genuine BMW brand with pride and has the parts you need to complete your next project with confidence.
This item fits the following BMWs:
1993-1995 E34 BMW 530i 540i
1997-2003 E39 BMW 540i
1992-1994 E32 BMW 740i 740ili
1995-2001 E38 BMW 740i 740il
2000-2003 E53 BMW X5 4.4i X5 4.6is
1990-1998 E31 BMW 840i 840ci
If there is a large amount of oil on the sides of the engine or if you can smell burning oil, chances are it's a bad valve cover gasket. The gasket fails and allows oil to seep down onto the side of the engine and other parts causing a mess and reducing the amount of oil in your engine. This replacement gasket from Elring is perfect to prevent any further oil leaks.
Includes the following Seals:
Elring is one of the biggest OEM names in the manufacturing of high quality gaskets that are available for very affordable prices. Elring has supplied many automotive names for years with the gaskets that seal your car's components from day 1 so you can rest assured that these components will last for a long time to come!
This item fits the following BMWs:
BMW M Series - M5, M6
BMW M50 M52 M54 S52 Valve Cover Securing Nut - Priced Each is a high-quality replacement component designed to securely fasten the valve cover to the engine. Essential for maintaining proper engine performance and preventing leaks, this securing nut is an exact fit for BMW models with M50, M52, M54, and S52 engines. Manufactured to OEM specifications by Turner Motorsport, it ensures durability and reliability.
