Cylinder Head and VANOS Tools for BMW Z3 (1996-2002)

When servicing your vehicle's VANOS system, get the job done easier with this socket specifically designed for the removal of the VANOS solenoid.

Features:

• 85mm from end to end
• 1/2" drive
• 32mm with a depth of 70mm.

If you have ever attempted to do a valve job or cylinder head gasket project on an M42, M44, M50, or M52 engine you know that the repair manual will refer to the special BMW timing tool kit. This tool kit includes a flywheel locating lock pin, and a special set of camshaft locators that lock the cams in a precise location. The tools are very easy to install. The kit is specifically designed to hold the engine and cams in proper timing during the cylinder head removal and re installation process. This avoids the chance of bending the valves doing the head install process. The precision ground holding blocks lock over the square ends of both intake and exhaust cams. The CNC machined flywheel locating pin passes through a hole in the rear of the engine block and passed through a machined hole in the flywheel.

To avoid improper cam timing on the latest BMW engines, the factory has devised a cam timing system that locks the crankshaft and cams into a specific position prior to cylinder head removal. This method was devised to avoid any misalignment, resulting in piston to valve damage. Unfortunately without these tools re-timing the camshafts after a valve job is almost impossible. The factory specification manual does not supply installation specifications. This cam timing kit includes all the necessary components to do the job.

This item fits the following BMWs:
1990-1991 E30 BMW 318i 318is 318ic
1992-1998 E36 BMW 318i 318is 318ti 318ic 323is 323ic 325i 325is 325ic 328i 328is 328ic M3
1999-2005 E46 BMW 323i 323ci 325i 325ci 325xi 328i 328ci 330i 330ci 330xi

NOTE: Not compatible with S50B30 and S50B32 Euro engines!If you have ever attempted to do a valve job or cylinder head gasket project on an M42, M44, M50, or M52 engine you know that the repair manual will refer to the special BMW timing tool kit. This tool kit includes a flywheel locating lock pin, and a special set of camshaft locators that lock the cams in a precise location. The tools are very easy to install. The kit is specifically designed to hold the engine and cams in proper timing during the cylinder head removal and re installation process. This avoids the chance of bending the valves doing the head install process. The precision ground holding blocks lock over the square ends of both intake and exhaust cams. The CNC machined flywheel locating pin passes through a hole in the rear of the engine block and passed through a machined hole in the flywheel.



The Schwaben Piston Ring Filer is a vital tool for obtaining the precise end gap necessary for optimal piston ring performance.

This filer allows you to swiftly and accurately file piston rings to exact measurements, enhancing your engine’s efficiency and lifespan. By simply positioning the piston ring and turning the handle, you can easily rotate the abrasive wheel for a smooth and effective filing process.

**Note:** For the Schwaben Universal Piston Ring Compressor, check out T25805755!

Key Features:

• Optimize Performance: Achieve the perfect end gap crucial for top engine efficiency.
• Quick and Precise: File rings to exact specifications with ease.
• Easy Operation: Position the piston ring and turn the handle to effortlessly rotate the abrasive wheel.
• Enhanced Engine Longevity: Accurate end gaps contribute to longer engine life and better performance.

Instructions:

1. Position the Ring: Place the piston ring on the outer edge against the stop and align the ends squarely against the grinding wheel. Apply light, even pressure against the wheel to prevent grinding too large a gap.
2. Operate the Tool: Turn the handle so the grinding wheel turns towards the inside edge of the ring (counter-clockwise when viewed from the handle side of the tool).
3. Exercise Caution: This is a diamond grinding wheel. It cuts fast!

Checking Piston Ring Gap:

1. Deburr the Ring Ends: Carefully remove any burrs on the ring ends before placing the ring in the bore. A light touch with a fine abrasive stone works well.
2. Clean the Rings: Thoroughly clean the rings with lacquer thinner or acetone, as the paint coating from the factory may occasionally scratch the cylinder bore. Always wear gloves during this process.
3. Position the Ring in the Cylinder: Place the ring squarely in the cylinder bore, about 1" down from the deck surface. An upside-down flat-top piston will help you properly square the ring.
4. Measure the End Gap: Use a feeler gauge to measure the ring's end gap. Apply light grinding pressure and check frequently to avoid making the end gap too large.

WARNING: This product contains chemicals known to the state of California to cause cancer, birth defects, and/or reproductive harm. See above warning label as well as http://www.p65warnings.ca.gov for further information on Proposition 65 warnings.

Looking to update your old torque wrenches? The Schwaben 3/8" Drive Digital Torque Wrench is your answer.

This digital torque wrench uses an easy-to-read display to show torque amounts and settings, features a push button release, reversible 3/8" drive, 45 tooth ratchet head, and a comfortable no-slip grip and adjustment wheel.

Specifications:

• Setting Range: 45-220 ft lbs (60-300 Nm)
• Display Units: ft-lbs, N-m, Inch-lbs, cm-kg2, and m-kg
• Size: 22" (550mm) length for easy leverage
• Accuracy: +- 3%
• Include blow molded holding case
• Requires one 3V CR2030 battery (included)

Schwaben Professional Mechanic's Work Gloves provide exceptional hand protection with a perfect balance of durability and comfort.

Designed for precision, these gloves offer high dexterity, making it easy to handle even the smallest parts. The tailored elastic cuff with a hook-and-loop closure ensures a secure and comfortable fit.

The textured latex coating on the palm and fingertips delivers superior grip and tactile feedback, while the breathable spandex backing and knit top allow for all-day comfort.

The durable synthetic leather palm enhances longevity, and the unique graphic design reflects the drifting culture of Euro car enthusiasts.

Note: See manufacturers information tab for sizing chart.

Key Features:

• High Dexterity: Perfect for picking up small parts with ease.
• Secure Fit: Tailored elastic cuff with a hook-and-loop closure.
• Enhanced Grip: Textured latex coating on palm and fingertips.
• All-Day Comfort: Breathable spandex backing and knit top.
• Durable Design: Synthetic leather palm for extended wear.
• Unique Style: Graphic design inspired by the drifting culture of Euro owners.

WARNING: This product contains chemicals known to the state of California to cause cancer, birth defects, and/or reproductive harm. See above warning label as well as http://www.p65warnings.ca.gov for further information on Proposition 65 warnings.

COMBINATION WRENCH SET:

Quality combination wrenches are a must when doing any kind of automotive work.

Features:

• A complete set from 8 to 19 mm
• Professional quality wrenches in full length feature open end on one end and 12 pt box on the other
• Satin finish provides superior feel, slip resistant grip, easy cleanup and inhibits rust
• Includes sturdy wrench holder for easy storage

SCRAPER, HOOK, AND PICK SET:

Some of the most popular uses are carbon cleaning/scraping, picking out o-rings, snap rings and clips. This kit features large and small picks, hooks and a 1" wide scraper. This 9pc set should be part of everyone's tool assortment.

Features:

• 3" Blade MINI Awl, 90°, Hook, and Curve
• 6" Blade Awl, 90°, Hook, and Curve
• 6" x 1" wide scraper

Everything in this kit comes with LIFETIME REPLACEMENT.

WARNING: This product contains chemicals known to the state of California to cause cancer, birth defects, and/or reproductive harm. See above warning label as well as http://www.p65warnings.ca.gov for further information on Proposition 65 warnings.
