E30 24v Swap Oil Pan

The No-Compromise Oil Pan for Your 24V E30 Build

Every E30 swap story starts the same way: you want the reliability and power of a modern BMW 24V engine - M50, M52, S50, or S52 - but without heavy modifications or a list of oil pan parts that are no longer available(NLA). You’ve read the forums, seen the DIYs, and done the math. And you’re still faced with the same question: how am I going to find all of these parts and make them work?

That’s exactly the problem we set out to solve.

At Turner Motorsport, we’ve been building BMWs for decades. We've performed the swaps, turned the wrenches, and taken the laps. The Turner Fabricated Oil Pan was born out of that experience, an enthusiast-engineered solution that eliminates the guesswork and lets you focus on what really matters: driving.

We designed this oil pan from the ground up to support 24V engine swaps into the E30 chassis, with zero permanent modifications.

Crafted from TIG-welded 5052 aluminum, this pan is as durable as it is lightweight. The brushed anodized finish adds a subtle shine under the hood and guards against corrosion for long-term reliability. Inside, we’ve integrated full-length oil control baffles with trap doors, ensuring your oil stays where it needs to be, even under the most aggressive acceleration, braking, and cornering.

The low-profile design is perfect for lowered cars, and the 8 mm-thick flange ensures a proper seal with the factory gasket. We didn’t stop there, every pan includes a billet aluminum oil pickup with an integrated stainless mesh screen that’s fully serviceable, a 304 stainless steel dipstick tube, and a billet rear transmission plate that allows you to utilize the lower mounting holes, unlike the stock E34 pan.

Whether you're building a high-performance street car, a dedicated track weapon, or a clean restomod, this oil pan offers OEM-level integration with aftermarket performance. It’s the cleanest, easiest, and most effective way to run a 24V engine in your E30 — built by BMW lovers, for BMW lovers.

Design:

Fully TIG-welded 5052 aluminum construction
Brushed anodized finish for a clean look and corrosion resistance
Engineered specifically for M5X/S5X engines in the BMW E30 chassis
Front-sump design clears the factory E30 subframe, no cutting or modification required
Designed and tested in-house by BMW enthusiasts
Features:

Built-in oil control baffles with trap doors to prevent starvation under cornering
Low-profile design for maximum ground clearance - perfect for lowered cars
Billet aluminum oil pickup with integrated stainless mesh screen - fully serviceable
8mm thick flange ensures a reliable seal with OEM gasket
Works with all standard 24V swap motor mounts
3/8" NPT port for turbo oil drain and 1/4" NPT for OBD2 CCV drain
Compatible with G260 and ZF transmissions
Stainless steel dipstick tube (304) included for strength and appearance
Utilizes E36 Dipstick (P# - 11431427993)
Kit Contents:

Turner Fabricated Oil Pan
Billet Rear Mounting Plate
304SS Dipstick Tube with Mounting Hardware
Billet Aluminum Oil Pickup
Optional: Oil Pan Gasket, Oil Filter, and Motor Oil
Optional: Complete Install Hardware Kit
Why It Works:

Direct fitment for M5X/S5X into E30, no cutting or fabrication required
Maximum clearance for front subframe, steering rack, and lowered suspension setups
Track-proven baffling to prevent oil starvation under load
Transmission compatibility with G260 and ZF gearboxes
Built by enthusiasts, designed and tested in-house on real cars

Turner Motorsport

T#: 41188178 | Part#: 052727LA

1 of

2 of

3 of

4 of

5 of

6 of

7 of

8 of

9 of

10 of

11 of

12 of

13 of

14 of

15 of

16 of

17 of

18 of

19 of

20 of

21 of

22 of

23 of

24 of

25 of

26 of

27 of

28 of

29 of

30 of

31 of

32 of

33 of

34 of

35 of

36 of

37 of

38 of

39 of

40 of

41 of

42 of

43 of

44 of

45 of

46 of

47 of

48 of

49 of

50 of

51 of

52 of

53 of

54 of

Checking Vehicle Fitment...

$1313.99

Starting at $1313.96

$1313.96

With selected options

Free Shipping

Availability:

In Stock

Est. Ship Date:

Today

Qty

Add to Wish List

Product Details

The No-Compromise Oil Pan for Your 24V E30 Build

That’s exactly the problem we set out to solve.

We designed this oil pan from the ground up to support 24V engine swaps into the E30 chassis, with zero permanent modifications.

Design:

Fully TIG-welded 5052 aluminum construction
Brushed anodized finish for a clean look and corrosion resistance
Engineered specifically for M5X/S5X engines in the BMW E30 chassis
Front-sump design clears the factory E30 subframe, no cutting or modification required
Designed and tested in-house by BMW enthusiasts

Features:

Built-in oil control baffles with trap doors to prevent starvation under cornering
Low-profile design for maximum ground clearance - perfect for lowered cars
Billet aluminum oil pickup with integrated stainless mesh screen - fully serviceable
8mm thick flange ensures a reliable seal with OEM gasket
Works with all standard 24V swap motor mounts
3/8" NPT port for turbo oil drain and 1/4" NPT for OBD2 CCV drain
Compatible with G260 and ZF transmissions
Stainless steel dipstick tube (304) included for strength and appearance
Utilizes E36 Dipstick (P# - 11431427993)

Kit Contents:

Turner Fabricated Oil Pan
Billet Rear Mounting Plate
304SS Dipstick Tube with Mounting Hardware
Billet Aluminum Oil Pickup
Optional: Oil Pan Gasket, Oil Filter, and Motor Oil
Optional: Complete Install Hardware Kit

Why It Works:

Direct fitment for M5X/S5X into E30, no cutting or fabrication required
Maximum clearance for front subframe, steering rack, and lowered suspension setups
Track-proven baffling to prevent oil starvation under load
Transmission compatibility with G260 and ZF gearboxes
Built by enthusiasts, designed and tested in-house on real cars

Product development:

Our swap pan components are designed, engineered, tested, and quality inspected by our Research and Development team at Turner. Nothing but the highest level of precision and quality through leading-edge product development technology, including FARO laser scanning for reverse engineering and quality inspection, SolidWorks 3D CAD modeling, rapid prototyping utilizing our in-house 3D printer, and rigorous long-term product testing.

Prop 65 Warning

Product Q&A

Lifetime Replacement

Fits These Cars

MAKE	MODEL	SUBMODEL	ENGINE	Special Fitment Notes
BMW	E30	318i	M10 1.8L	Use vehicle selector to confirm fitment
BMW	E30	318i	M42 1.8L	Use vehicle selector to confirm fitment
BMW	E30	318is	M42 1.8L	Use vehicle selector to confirm fitment
BMW	E30	325	M20 2.7L	Use vehicle selector to confirm fitment
BMW	E30	325e	M20 2.7L	Use vehicle selector to confirm fitment
BMW	E30	325es	M20 2.7L	Use vehicle selector to confirm fitment
BMW	E30	325i	M20 2.5L	Use vehicle selector to confirm fitment
BMW	E30	325is	M20 2.5L	Use vehicle selector to confirm fitment
BMW	E30	325ix	M20 2.5L	Use vehicle selector to confirm fitment
BMW	E30	M3	S14 2.3L	Use vehicle selector to confirm fitment
