Oiling System for BMW 3 Series E30 (1984-1991)

When we designed this catch we wanted to have the most function options available, the best separation method, and the easiest to service. The Turner engineered catch cans offer a pre-setup design based ion desired flow direction, however this does not limit you to this flow. The inner baffle orientation can be easily adjusted to flow in both directions in case you decide to move this catch can to a different vehicle. A 4 chamber system  baffle system inside the catch can was engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can. Having a closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation.

Our catch can was also designed with the idea that the cans fill level can easily be checked with a top mounted dipstick and an optional use bottom drain hole. The drain hole can be used with a valve and hose to be mounted at a lower area of the vehicle so when you're doing an oil change you can drain the catch can.

Features:

• 6061-T6 billet machined body, anodized black for lasting protection and appearance
• Strategically positioned 4 chamber baffle system maximizes oil / air separation
• Knurled and black anodized oil dipstick makes inspecting oil volume of reservoir clean and simple
• Sealed with a pre-installed viton O-Ring
• Includes 2.5mm allen key to remove baffle plates for cleaning
• Engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can
• Closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation
• Optional use drain hole (valve and hose sold separately, watch for our model specific drain kits!)

Elevate your custom installation with the ECS -10AN O-Ring Boss fitting, a crucial component that connects your ECS Tuning Catch Can to a 3/4" ID hose. This fitting simplifies your plumbing setup, ensuring a seamless solution.

Featuring a pre-installed Viton O-ring, this fitting is engineered for excellence, providing a leak-proof seal that resists the effects of oil and fuel exposure, guaranteeing long-term durability.

The 3/4" nipple is thoughtfully designed with barbs to secure hose position effectively, minimizing the risk of hose disconnection. Keep in mind that clamps and hoses are available for separate purchase. These fittings are sold individually, with most installations requiring a pair of them.

The intermediate shaft bearings are located in the engine block (an inner and outer bearing). The intermediate shaft is driven from the timing belt and spins the oil pump shaft. Whenever the engine is torn down and the block is chemically or thermally cleaned these bearings will need to be replaced. The bearings must be sized with the intermediate shaft! The bearing surfaces must be machined to the correct tolerance for the block and shaft! You must make your engine builder aware of this before final assembly.

Note: these bearings must be machined for the shaft and block.

M20 block uses inner and outer bearings but the bearings are the same part numbers.

When doing any sort of repair or maintenance there is no replacement for genuine factory parts. Turner Motorsport carries the Genuine BMW brand with pride and has the parts you need to complete your next project with confidence.

Optimize your vehicle's performance and shield crucial components with the Mishimoto Compact 2-Port Baffled Oil Catch Can. This innovative solution effectively separates oil particles from PCV/CCV air using a 50-micron bronze filter, ensuring defense against oil blow-by for your intercooler, intake system, and vital parts. Constructed with a patented billet 6061 aluminum can sealed with Viton™ O-Rings, this catch can guarantees both durability and effectiveness.

Equipped with a universal mounting bracket, it allows adaptable installation and comes complete with two CNC-machined aluminum 1/2" barbed hose fittings. With an enhanced 3 oz internal capacity, service intervals are prolonged, while its fully serviceable filter and can ensure enduring functionality.

Engineered for safety in pressurized applications, the internal air diverter enhances oil separation by amplifying air turbulence. Available in black, red, or polished finishes, this catch can preserves proper octane levels, reducing potential detonation and promoting extended engine life.

The product package includes the Compact 2-Port Baffled Oil Catch Can, two Aluminum 1/2" Barbed Fittings, and a Universal Mounting Bracket, all backed by the Mishimoto Lifetime Warranty.
