BMW Electrical Sensors, Switches, & Relays for BMW 6 Series E63 (2004-2010)

All vehicles will lose some degree of performance due to heat soak under the right operating conditions.  Engine management systems constantly monitor operating conditions and modifying parameters based on sensor inputs. BMW integrated the intake air temp sensor in the MAF housing on models such as the E39 M5, and, being sandwiched behind a hot radiator and in some applications next to an even hotter valve cover, this is less than ideal for performance applications. Absorbing excess heat from its surroundings, the MAF can’t shed it fast enough, and the ECU reads an inaccurately high intake air temperature. Compensating for this false hot air measurement, the ECU pulls timing and runs a richer fuel mixture, resulting in a significant loss of torque.

What can you do?  Locate an intake air temp sensor in a location where it can properly measure incoming air temps and where it's less prone to heat soak. Mounting the sensor further away from the heat source and isolating it from the MAF housing, it can both resist the effects of heat soak longer and respond to temperature changes more quickly.  The result is you’ll experience reduced torque loss and more consistent power output when you’re pushing your engine hard.

The Turner engineering team was initially skeptical of the claimed performance benefits of this modification. They first set out validate the functionality and performance benefit of a temp sensor relocation. Replicating stop-and-go traffic heat soak in a 2001 540i was a simple task in a controlled environment - their dynometer. First the car was heat soaked to simulate being stuck in traffic or moving at low speeds by running the car four times on the dyno with the dyno's cooling fans disabled. The fans were then turned on for three more runs to observe the recovery rate once air flow was reintroduced. The test: following this procedure once with a stock IAT, and once with their relocation kit in place.

The result? Turner recovered 11lb-ft torque at 2500rpm through use of their relocation kit, with even greater recovery to be found for M5 owners. Here are the heat soak-related torque losses Turner experienced:

Stock IAT location:
18rwtq at 2500rpm
10rwtq at 3000rpm
9rwtq at 3700rpm

Turner IAT Relocation:
7rwtq at 2500rpm
5rwtq at 3000rpm
5rwtq at 3700rpm

**Click here for installation instructions**

The Turner engineering team designed a complete plug and play kit (unlike all other options on the market) that makes for quick, easy, and reversible installation. Weather-sealed connectors keep out the elements, while sheathed wiring offers a clean appearance underhood. With a harness nearly 3 feet long - the Turner IAT relocation kit offers flexibility in positioning, but not too long that you're left with unsightly excess wiring. Turner recommends positioning the sensor in a location away from engine heat, but still within the intake ducting to achieve accurate intake temp readings - such as the far side of the base of the airbox. Vehicles with cold air intakes with cone-style filters can even position the sensor in the end of the filter. Simply drill a hole in your (cool) location of choice and plug in the harness. More information including installation instructions and some good examples of sensor mounting locations can be found in our DIY PDF.

We include everything you need to relocate your IAT, just select your desired sensor brand below - Genuine BMW or original equipment Beru.

Also the perfect plug-n-play option for anyone looking to upgrade their intake to utilize an Alpha-N tune!

Note for vehicles with M62 engine: applicable to 1999 and up

Features & Benefits:

Two configurable linear 0-5V analog outputs Ability to calibrate O2 sensors for maximum accuracy Includes LC-2 controller and Bosch wideband O2 sensor Comes with a program cable, manual, and a 10 ft. sensor cable Includes a 1-inch mild steel exhaust bung Innovate MTS serial in/out capability Integrated dual-color status LED (green/red) Patented DirectDigital™ wideband sensor control Positive lock connectors for all connections Real-time display data on screen or with the powerful LogWorks software Range:

AFR (Air-Fuel Ratio) range from 7.4:1 to 22.4:1 (0.5 to 1.5 lambda)

This is a Valeo brand new 170 amp alternator. These alternators are built especially for extremes of heat, cold and high demand. Your BMW deserves nothing less than the best, which is why an OEM alternator is the best option. BMW alternators are built to last using the highest quality materials and the most technologically advanced processes. All alternator parts are 100% factory tested to assure that they meet or exceed original equipment specifications. And every alternator is fully load tested to guarantee compliance with BMW's strict performance specifications.

No core charge!

This item fits the following BMWs:
2006-2010 E60 BMW M5
2006-2010 E63 BMW M6

A faulty camshaft position sensor will result in timing issues and rough idle/engine operation or light up the check engine light. Get rid of your check engine light and restore smooth operation with this OEM VDO sensor.

OEM VDO is one of the largest OE providers in the world, supplying numerous vehicle brands, including BMW, with many of their genuine parts that build the vehicle before they ever reach the car lot. Entrusted by many of the top names in automotives and with their proven history of reliability, it makes all of us here at Turner confident that their line of OEM replacement parts are a perfect option to restore your vehicles original operation and performance. The same great quality or higher than Genuine BMW parts at a lower cost.

As a leading source of high performance BMW parts and accessories since 1993, we at Turner Motorsport are honored to be the go-to supplier for tens of thousands of enthusiasts the world over. With over two decades of parts, service, and racing experience under our belt, we provide only quality performance and replacement parts.  All of our performance parts are those we would (and do!) install and run on our own cars, as well as replacement parts that are Genuine BMW or from OEM manufacturers. We only offer parts we know you can trust to perform!

The Superior Bass Sports Horn Kit 330Hz + 400Hz 112Db is designed to make sure your presence is known with powerful, attention-grabbing sound. These high-performance sports horns feature:

• Impressive Loudness: Delivers a powerful 112 decibels, ensuring you’re heard in any situation.
• Dual Frequency: Includes 330Hz and 400Hz horns for a dynamic and distinct sound.
• Lightweight & Durable: Constructed for easy installation with weather-resistant covers, built to withstand the elements.
• Easy Installation: Quick and straightforward to install, enhancing vehicle safety with minimal effort.

The kit is a must-have for anyone looking to enhance their vehicle’s horn performance and visibility on the road.

This Siemens VDO Eccentric Shaft Sensor for the Valvetronic valve timing system on BMW N62,N73, and N62N engines. This sensor is mounted on the rear of the engine near the firewall. Sold individually.

OEM VDO is one of the largest OE providers in the world, supplying numerous vehicle brands, including BMW, with many of their genuine parts that build the vehicle before they ever reach the car lot. Entrusted by many of the top names in automotives and with their proven history of reliability, it makes all of us here at Turner confident that their line of OEM replacement parts are a perfect option to restore your vehicles original operation and performance. The same great quality or higher than Genuine BMW parts at a lower cost.

As a leading source of high performance BMW parts and accessories since 1993, we at Turner Motorsport are honored to be the go-to supplier for tens of thousands of enthusiasts the world over. With over two decades of parts, service, and racing experience under our belt, we provide only quality performance and replacement parts.  All of our performance parts are those we would (and do!) install and run on our own cars, as well as replacement parts that are Genuine BMW or from OEM manufacturers. We only offer parts we know you can trust to perform

This item fits the following BMWs:
2004-2010 E60 BMW 545i 550i
2004-2010 E63 BMW 645ci 650i
2002-2008 E65 BMW 745i 745li 750i 750li 760i 760li
2004-2006 E53 BMW X5 4.4i X5 4.8is
2007-2010 E70 BMW X5 4.8i X5 xDrive48i

Ensure smooth engine operation in your BMW N62 N73 Engines with this Bremmen Parts Eccentric Shaft Sensor. Designed to detect valve position and lift adjusted by the Valvetronic motor, this sensor prevents poor cold-start issues and rough idle caused by valve lift failure. Avoid potential limp mode situations with this reliable replacement sensor, which also requires a valve cover gasket replacement for proper installation.

Key Benefits:

Detects valve position and lift for optimal engine performance Prevents poor cold-start issues and rough idle Avoids potential limp mode situations Compatible with N62 N73 Engines
