Catch Can for BMW 3 Series E90 (2006-2011)

When we designed this catch we wanted to have the most function options available, the best separation method, and the easiest to service. The Turner engineered catch cans offer a pre-setup design based ion desired flow direction, however this does not limit you to this flow. The inner baffle orientation can be easily adjusted to flow in both directions in case you decide to move this catch can to a different vehicle. A 4 chamber system  baffle system inside the catch can was engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can. Having a closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation.

Our catch can was also designed with the idea that the cans fill level can easily be checked with a top mounted dipstick and an optional use bottom drain hole. The drain system comes complete with a valve and hose to be mounted at a lower area of the vehicle so when you're doing an oil change you can drain the catch can.

Features:

• 6061-T6 billet machined body, anodized black for lasting protection and appearance
• Strategically positioned 4 chamber baffle system maximizes oil / air separation
• Knurled and black anodized oil dipstick makes inspecting oil volume of reservoir clean and simple
• Sealed with a pre-installed viton O-Ring
• Includes 2.5mm allen key to remove baffle plates for cleaning
• Engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can
• Closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation
• Optional use drain hole - drain kit included!
• Universal mounting kit

There are a few reason having a catch can is an upgrade for a vehicle, from a separator system that no longer works to one that was never there. Modern day emissions regulations require the use of a closed crankcase ventilation (PCV) system to recirculate combustion blow-by gases from the crankcase back in to the intake to be burned.  Unfortunately, these blow by gases contain water vapor (which is a byproduct of combustion) and pick up oil mist from and the windage cloud and cam lubrication system as they travel through the crank case.  Due to less than 100% effective air/oil separation in the stock PCV system, some oil mist and water vapor gets carried back to the intake tract and over time cause oil deposits and carbon buildup in the intake manifold, intake ports, and on the back of intake valves.  All will eventually lead to poor performance and reduced fuel economy, and the presence oil mist can in the intake charge even increase the risk of engine damaging detonation.

With direct injected engines this problem becomes more prevalent, and the N54 in your 135i or 335i is no exception.  We're seeing a lot of N54 powered cars with drivability and performance issues due to significant carbon buildup in the intake ports and backs of intake valves.  The “factory fix” is a walnut blasting service that commonly needs performed every 30,000 to 70,000 miles.  Don't be part of this statistic!  Our shop recommends an oil catch can be installed in-line in the PCV system to help reduce the build-up of performance robbing deposits and greatly reduce the need for costly walnut blasting service and related repairs in the future.

​ The catch can utilizes a strategically designed 4 chamber baffle plate system engineered to create multiple changes in the direction of airflow to cause oil droplets to fall out of suspension, maximizing the efficiency of the PCV air/oil separation.  A dipstick is integrated into the cap so you can monitor the oil level, and the can is easily serviced.  At each oil change simply unscrew the canister and empty the trapped oil with your regular used oil.  The Turner Motorsport Oil Catch Can is CNC machined from billet 6061-T6 aluminum and with a stealthy black anodized finish for lasting durability and appearance, and includes everything needed for an OEM-like fully reversible installation. Another feature the Turner catch can has is the ability to add on a drain kit so you no longer have to fumble around getting the fill can out of a tight space. The drain can be run down to the belly pan of your car so draining can be done at the same time you change your oil or anytime in between.

*Click here for catch can instructions*

Features:

• 6061-T6 billet machined body, anodized black for lasting protection and appearance
• Strategically positioned 4 chamber baffle system maximizes oil / air separation
• Knurled and black anodized oil dipstick makes inspecting oil volume of reservoir clean and simple
• Sealed with a pre-installed viton O-Ring
• 8oz reservoir
• Includes 2.5mm allen key to remove baffle plates for cleaning
• Engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can
• Closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation
• Optional use drain hole - drain kit included!
• Passenger side mounting kit - Designed specifically for your N54!

There are a few reason having a catch can is an upgrade for a vehicle, from a separator system that no longer works to one that was never there. Modern day emissions regulations require the use of a closed crankcase ventilation (PCV) system to recirculate combustion blow-by gases from the crankcase back in to the intake to be burned.  Unfortunately, these blow by gases contain water vapor (which is a byproduct of combustion) and pick up oil mist from and the windage cloud and cam lubrication system as they travel through the crank case.  Due to less than 100% effective air/oil separation in the stock PCV system, some oil mist and water vapor gets carried back to the intake tract and over time cause oil deposits and carbon buildup in the intake manifold, intake ports, and on the back of intake valves.  All will eventually lead to poor performance and reduced fuel economy, and the presence oil mist can in the intake charge even increase the risk of engine damaging detonation.

With direct injected engines this problem becomes more prevalent, and the N54 in your 135i or 335i is no exception.  We're seeing a lot of N54 powered cars with drivability and performance issues due to significant carbon buildup in the intake ports and backs of intake valves.  The “factory fix” is a walnut blasting service that commonly needs performed every 30,000 to 70,000 miles.  Don't be part of this statistic!  Our shop recommends an oil catch can be installed in-line in the PCV system to help reduce the build-up of performance robbing deposits and greatly reduce the need for costly walnut blasting service and related repairs in the future.

​ The catch can utilizes a strategically designed 4 chamber baffle plate system engineered to create multiple changes in the direction of airflow to cause oil droplets to fall out of suspension, maximizing the efficiency of the PCV air/oil separation.  A dipstick is integrated into the cap so you can monitor the oil level, and the can is easily serviced.  At each oil change simply unscrew the canister and empty the trapped oil with your regular used oil.  The Turner Motorsport Oil Catch Can is CNC machined from billet 6061-T6 aluminum and with a stealthy black anodized finish for lasting durability and appearance, and includes everything needed for an OEM-like fully reversible installation. Another feature the Turner catch can has is the ability to add on a drain kit so you no longer have to fumble around getting the fill can out of a tight space. The drain can be run down to the belly pan of your car so draining can be done at the same time you change your oil or anytime in between.

*Click here for catch can instructions *

Features:

• 6061-T6 billet machined body, anodized black for lasting protection and appearance
• Strategically positioned 4 chamber baffle system maximizes oil / air separation
• Knurled and black anodized oil dipstick makes inspecting oil volume of reservoir clean and simple
• Sealed with a pre-installed viton O-Ring
• 8oz reservoir
• Includes 2.5mm allen key to remove baffle plates for cleaning
• Engineered to create multiple changes in the direction of airflow within the separator to cause oil droplets to fall out of suspension before exiting the catch can
• Closed / recirculated design reduces oil ingestion and promotes cleaner emissions and odor-less operation
• Optional use drain hole - drain kit included!
• Driver side mounting kit - Designed specifically for your N54!

Elevate your custom installation with the ECS -10AN O-Ring Boss fitting, a crucial component that connects your ECS Tuning Catch Can to a 3/4" ID hose. This fitting simplifies your plumbing setup, ensuring a seamless solution.

Featuring a pre-installed Viton O-ring, this fitting is engineered for excellence, providing a leak-proof seal that resists the effects of oil and fuel exposure, guaranteeing long-term durability.

The 3/4" nipple is thoughtfully designed with barbs to secure hose position effectively, minimizing the risk of hose disconnection. Keep in mind that clamps and hoses are available for separate purchase. These fittings are sold individually, with most installations requiring a pair of them.

Meet modern emission regulations while preserving engine performance with the ECS Baffled Oil Catch Can. Designed for BMW and MINI vehicles, this system efficiently captures blow-by gases, preventing excessive oil vapor ingestion into the intake tract. The innovative 4-chamber baffle system maximizes oil/air separation, reducing carbon build-up and pollutants. Featuring a 1/4" drain fitting for easy maintenance, this catch can minimizes oil deposits, ensuring cleaner emissions and enhanced engine performance.

Key Benefits:

• Efficient 4-chamber baffle system for maximum oil/air separation
• Recirculated design reduces oil ingestion, promoting cleaner emissions
• Durable 6061-T6 billet machined body with anodized black finish for longevity
• Integrated dipstick and sealed reservoir for easy oil inspection and maintenance
• Serviceable design with removable baffle plates for cleaning
• Easy installation with customizable mounting options and leak-free fittings
• Engineered and manufactured in the USA for superior performance and durability

Note: Not for sale or use in the state of California on any pollution-controlled vehicle as per the California Air Resources Board.

Oil venting and circulation continues to be a problem on BMW engines and now even more so on the turbocharged N54 and N55 engines. The existing stock system does a very poor job of separating fluid and vapor and this leads to an oily film or even small pools of oil throughout the turbos and intake. We're seeing a lot more 135 and 335 cars with drivability and performance issues because oil has sneaked by the ring seals and is coating the intake piping, intercooler, intake valves, and other critical areas. The problem is worsened with higher boost levels. Oil is excellent for lubricating moving parts but terrible when it gets into the combustion chamber, effectively lowering the octane rating and reducing performance. Our own shop has gone the extra step and offers media blasting of the intake valves to strip away the oily buildup we have seen.

Our shop also strongly recommends an oil catch can be installed in the line for the crankcase vent. The oil catch can traps oil as it leaves the valve cover and holds it in a canister. Whatever minimal vapors are left over in the oil is then vented back through the canister and into the intake where it is safe to be burned up in the engine or recirculated back through the system again. This is the way the system was designed! At each oil change simply unscrew the canister and empty the trapped oil with your regular used oil. A dipstick is integrated into the cap so you can monitor the oil level. Installing one of these will avoid costly repairs in the future and help maintain your boost and performance. It's one of the smartest modifications you can make because it demonstrates a well-thought out tuning strategy and care for the condition of your engine.

The ECS Oil Catch Can is made from aluminum and with a stealthy black anodized finish. Multiple brackets are available so you're not limited on where to mount it. The location is key as heat will evaporate the oil and send too much vapor back into the engine (where cooler air will turn it back into fluid). The ECS OCC also has a factory-like appearance.

Note: Since the crankcase vent system is considered part of the overall emissions system, installing this may be a violation of local, state, and federal laws. While exemptions are made for track/race and off-road use, check with your local state inspection facility on using this in street-driven vehicles.

ECS Oil Catch Can Features:
+ Increases air intake efficiency
+ Promotes engine longevity
+ 4 chamber design promotes excellent air/oil separation
+ Large In/Out ports (no tapered sizes that slow flow)
+ Anodized black lightweight aluminum
+ Made in USA

This item fits the following BMWs with the N54 twin-turbo engine:
2008-2010 E82 BMW 135i
2007-2010 E9X BMW 335i 335xi
2006-2010 E60 BMW 535i 535xi
