Top Turner Suspension & Camber Products | E36 3 Series

Our sealed Monoball Rear Trailing Arm Bushings (RTAB) are the best solution for completely eliminating deflection and unwanted toe changes on the rear of the E36, E46, and Z4. While rubber and urethane bushings flex during load, the toe can change widely giving you nervous and unpredictable handling. These RTABs have a solid aluminum housing with a high-quality sealed OE bearing. These bushings were developed from years of competition use in various racing and HPDE events. There is simply no better RTAB unless your racing class rules prohibit the use of mono or spherical bearings.

The rear trailing arm bushings take a lot of abuse from acclerating, braking and cornering. The stock rubber bushings are just not up to the task of keeping rear wheel alignment in spec for very long, especially if you have upgraded to stickier tires and a better suspension. The pliable rubber flexes and twists which slows down reaction time and leaves you with a car that feels nervous and 'tail happy'. Urethane helps to control the alignment but issues with fitment, maintenance, and longevity keep us from recommending urethane on anything but a street car. We also offer a Delrin RTAB for cars that must conform to certain racing class rules. These sealed spherical bearings are the best at controlling rear toe alignment.

Our aluminum RTABs are very well made - high grade aluminum alloy and steel CNC'd out of a billet by an ISO 9001 certified manufacturer, each component is either hardcoated or nickel plated. While multiple manufacturers offer two piece designs, our research showed that a one piece bushing is a better design featuring a sealed bearing to keep contaminants out extending the life of the bearing.

Features:

Key Benefits:

• Rear Trailing Arm Monoball eliminates unwanted deflection, maintaining alignment settings and minimizing wheel hop.
• Allows full rear trailing arm articulation for low friction movement and eliminates binding found in rubber and poly bushings.
• Completely streetable: utilizes an OES Lemforder brand sealed, greased ball joint for an extremely long service life with no increase to NVH.

Design Features:

• Housing: Billet CNC 6061-T6 aluminum, type II anodized for exceptional durability and corrosion resistance
• Bearing: OE Mercedes/lemforder 2043520027 Sealed ball joint
• Bearing inserts: CNC machined 303 stainless steel.
• Rebuildable

Clickhere for installation instructions.

This item fits the following BMWs:
1992-1998 E36 BMW 318i 318is 318ic 323is 323ic 325i 325is 325ic 328i 328is 328ic M3
1999-2005 E46 BMW 323i 323ci 325i 325ci 325xi 328i 328ci 330i 330ci 330xi M3
2003-2008 Z4 BMW Z4 2.5i Z4 3.0i Z4 3.0si Z4 M Roadster M Coupe

If you're installing a rear shock on your E30/E36/E46/Z3/Z4 that utilizes a Spherical Bearing or Rod-End, commonly referred to as an "eye mount", and used with racing shocks/dampers, this is the upper rear mounts needed to attach your shock to the chassis. The mount is machined out of aircraft grade aluminum with a high quality coating and premium hardware. Note: 2 Bushing kits are included for common eyelet bearings; see chart for sizes. If you do not see the bushing kit you need, give us a call and have our in-house machine shop build you custom bushings.

Our Racing Rear Lower Shock Mount is machined out of aircraft grade aluminum. We include both the TSU9007B15 and TSU9007B50 bushing kits with this package.

This item fits the following BMWs:
1984-1991 E30 BMW 318i 318is 318ic 325e 325es 325i 325ic 325is 325ix M3
1992-1998 E36 BMW 318i 318is 318ti 318ic 323is 323ic 325i 325is 325ic 328i 328is 328ic M3
1999-2005 E46 BMW 323i 323ci 325i 325ci 325xi 328i 328ci 330i 330ci 330xi M3
1997-2002 Z3 BMW Z3 1.9 Z3 2.3 Z3 2.5i Z3 2.8 Z3 3.0i M coupe M Roadster
2003-2008 Z4 BMW Z4 2.5i Z4 3.0i Z4 3.0si Z4 M Roadster Z4 M coupe

These adjustable rear links are only required when using sway bar / swaybars with a suspension with a very low ride height, where it may be necessary to adjust the length of the end links for proper sway bar clearance from the drive axles or other suspension components. These suspensions are usually found only on race cars but this may also apply to street cars with sport springs/sport coil overs that are lowered a lot. On most street cars lowered 1.5" or less, the stock links will be fine.

These end links feature a Heim joint, which allows enough lateral movement when disconnected to adjust the length of the link without removing the entire link from the car. This is particularly helpful when eliminating or adjusting preload while tuning the suspension. Similar links without this joint, can't be adjusted without totally removing the link from the car.

Built-in grease fittings allow for occasional lube, and a packet of grease is included. These links are sold as a set, and include two end links and hardware for H&R and TMS sway bars (other brands may not need the hardware).

At their shortest setting they are 2.875" hole to hole and on their longest setting they are 3.5" hole to hole.

*Note: these links will not work with factory or non-adjustable Eibach sway bars.
