BMW Intake Parts for BMW X Series E84 (2013-2015)

Replacement N55 Performance Filter from Burger Motorsport

Enhance your BMW's performance with the Replacement N55 Performance Filter from Burger Motorsport. Specifically designed for N55 engines, this filter optimizes airflow, leading to increased horsepower and torque. Enjoy improved throttle response and fuel efficiency, all while protecting your engine from harmful contaminants.

Key Features:

• Designed for N55 engines
• Optimizes airflow for increased power
• Improves throttle response and fuel efficiency
• Protects engine from contaminants

GFB’s DV+ solution couldn’t be simpler - keep what works and replace what doesn’t.

Worldwide Patent and Design Patent Pending

• Retains the factory solenoid coil for seamless integration
• Replaces plastic valve parts with metal for reliability and strength on chipped engines
• Direct-fit replacement with GFB’s TMS benefits
• Exclusive “pilot-actuated” valve mechanism for rapid response at high boost

GFB expands the DV+ range with a direct-fit solution for the weak factory diverter valve used on many European vehicles.

The solenoid coil itself from the factory-fitted valve is great (the ECU opens it faster than any pneumatic valve so why replace it?), but the weak point however is the valve mechanism itself. So GFB’s DV+ solves this problem by replacing just the valve parts with an anodised billet aluminium housing fitted with a brass piston machined to exacting tolerances.

The end result is sharper throttle response, lightning-fast valve actuation, and it will hold as much boost as you can throw at it. Read all about the DV+ story on the next page.

Other manufacturers’ products involve replacing the entire system with a traditional pneumatic valve, requiring long vacuum hose runs, additional parts for tapping into the intake manifold vacuum, plus either a different solenoid valve to actuate the pneumatic valve or a ballast resistor to plug into the OE wiring loom. All these additional items result in a product that is slower, less responsive, more expensive and takes much longer to install.

GFB’s DV+ solution on the other hand is more responsive, less expensive, easier to install, and doesn’t cause compressor surge/turbo flutter. Oh, and it doesn’t require different springs or frequent re-builds.

Many late-model European cars use ECU controlled solenoid-type diverter valves. This is a good concept because the valve can react very quickly and it only opens when it needs to.

However, there are some problems with these valves. There are typically two types of solenoid-actuated diverter valves found standard on VAG and European cars, both of which have their shortcomings.

Common OE Problem #1
The diaphragm types are commonly known to rupture, especially when boost and temperature are increased as a result of chip tuning.

Common OE Problem #2
The plastic piston-type leaks far more than most people realise (by design, not from wear), and doesn’t always close after a high-boost gear shift.

Additionally, in both cases, the solenoid on the OE diverter is directly connected to the valve mechanism, which is not ideal because neither it nor the return spring are strong enough to open and close the valve reliably at high boost.

With problems like this, you can see why other aftermarket manufacturers assume the best solution is to replace the factory diverter entirely. Unfortunately though, whilst their replacement kits might be stronger than the factory diverter, their slower response speed and lower flow do not justify the extra cost and complexity - more of a compromise than a solution.

GFB has taken a different approach to deliver a complete solution that solves existing problems and improves performance, without compromise or a hefty price tag.

The DV+ addresses the factory valve problems with a very simple and elegant solution. Keeping the factory solenoid retains all the benefits of the stock system, and replacing the valve parts with indestructable metal components ensures strength and reliability no matter how much boost you run.

That's not all. Rather than using the solenoid to directly actuate the valve, we’ve introduced a unique “pilot-actuation” system. This means the solenoid controls the air pressure that is used to open and close the piston, so it doesn't matter how much boost you push through it, the DV+ will open and close reliably without ever exceeding the solenoid’s capability.

This feature also improves on the factory system by opening the valve progressively in response to boost pressure, so it only opens as much as required to get the job done (the factory valve simply opens and shuts, it cannot partially open if boost pressure is low), resulting in better throttle response.

• Seamless plug-and-play installation
• Minimizes leakage for enhanced turbocharger performance
• Retains OE control for optimal operation
• Superior thermal performance to maximize boost without stressing the turbocharger

Due to weak plastic construction, the factory plastic crankcase ventilation breather hose is known to fail. After years of exposure to piping-hot engine bay temperatures and chemical-laden oil vapors, the corrugated plastic tubing can crack, crumble, or fail altogether.

We set out to bulletproof your N20 PCV system with a durable silicone breather hose, designed to provide a comprehensive upgrade and permanent replacement for the factory plastic hose. By replacing the flimsy, heat-hardened OEM plastic hose with a four-ply fluorosilicone hose, you'll experience peace of mind knowing your N20 is free from the inevitable return of oil leaks, vacuum leaks, and drivability concerns that would have been.

This breather hose is found at the front of the engine, and is used to connect the inlet pipe to the valve cover. It replaces OEM part number 11127588417.

Features:

Silicone construction ensures a durable replacement that is sure to outlast OE plastic
Designed as a direct replacement for the factory breather hose
Retains heating function and OE electrical connector
Design:

Four-ply wire-reinforced fluorosilicone hose is designed to resist degradation due to exposure to oil vapors
O-rings are pre-installed in OE connectors for a lasting seal
Includes pre-installed zinc-coated hose clamps for durability and corrosion resistance
Product Development:

Our Silicone PCV Hose Upgrade was designed, engineered, tested, and quality inspected by our Research and Development team in our Wadsworth, Ohio, facility. We strive for the highest level of precision and quality through leading-edge product development technology, including FARO laser scanning for reverse engineering and quality inspection, SolidWorks 3D CAD modelling, rapid prototyping utilizing our in-house 3D printer, and rigorous long-term product testing.
