BMW Electrical Sensors, Switches, & Relays for BMW Z4 M Roadster S54 (2003-2008)

All vehicles will lose some degree of performance due to heat soak under the right operating conditions.  Engine management systems constantly monitor operating conditions and modifying parameters based on sensor inputs. BMW integrated the intake air temp sensor in the MAF housing on models such as the E39 M5, and, being sandwiched behind a hot radiator and in some applications next to an even hotter valve cover, this is less than ideal for performance applications. Absorbing excess heat from its surroundings, the MAF can’t shed it fast enough, and the ECU reads an inaccurately high intake air temperature. Compensating for this false hot air measurement, the ECU pulls timing and runs a richer fuel mixture, resulting in a significant loss of torque.

What can you do?  Locate an intake air temp sensor in a location where it can properly measure incoming air temps and where it's less prone to heat soak. Mounting the sensor further away from the heat source and isolating it from the MAF housing, it can both resist the effects of heat soak longer and respond to temperature changes more quickly.  The result is you’ll experience reduced torque loss and more consistent power output when you’re pushing your engine hard.

The Turner engineering team was initially skeptical of the claimed performance benefits of this modification. They first set out validate the functionality and performance benefit of a temp sensor relocation. Replicating stop-and-go traffic heat soak in a 2001 540i was a simple task in a controlled environment - their dynometer. First the car was heat soaked to simulate being stuck in traffic or moving at low speeds by running the car four times on the dyno with the dyno's cooling fans disabled. The fans were then turned on for three more runs to observe the recovery rate once air flow was reintroduced. The test: following this procedure once with a stock IAT, and once with their relocation kit in place.

The result? Turner recovered 11lb-ft torque at 2500rpm through use of their relocation kit, with even greater recovery to be found for M5 owners. Here are the heat soak-related torque losses Turner experienced:

Stock IAT location:
18rwtq at 2500rpm
10rwtq at 3000rpm
9rwtq at 3700rpm

Turner IAT Relocation:
7rwtq at 2500rpm
5rwtq at 3000rpm
5rwtq at 3700rpm

**Click here for installation instructions**

The Turner engineering team designed a complete plug and play kit (unlike all other options on the market) that makes for quick, easy, and reversible installation. Weather-sealed connectors keep out the elements, while sheathed wiring offers a clean appearance underhood. With a harness nearly 3 feet long - the Turner IAT relocation kit offers flexibility in positioning, but not too long that you're left with unsightly excess wiring. Turner recommends positioning the sensor in a location away from engine heat, but still within the intake ducting to achieve accurate intake temp readings - such as the far side of the base of the airbox. Vehicles with cold air intakes with cone-style filters can even position the sensor in the end of the filter. Simply drill a hole in your (cool) location of choice and plug in the harness. More information including installation instructions and some good examples of sensor mounting locations can be found in our DIY PDF.

We include everything you need to relocate your IAT, just select your desired sensor brand below - Genuine BMW or original equipment Beru.

Also the perfect plug-n-play option for anyone looking to upgrade their intake to utilize an Alpha-N tune!

Note for vehicles with M62 engine: applicable to 1999 and up

If you're experiencing hard starting, flaky charging, or other electrical issues, your engine ground strap may be the culprit. On older BMWs, the engine ground strap is a thin, non-insulated cable that spans from the engine mount arm to the frame horn. Despite the seemingly simple nature of this part, on older cars, it is known to cause massive headaches. Due to its non-insulated design, years of exposure to water, dirt, and road salt will cause the wire to corrode, ultimately leading to complete failure. A break in this cable will cause an open circuit, resulting in issues with the vehicle's electrical system and potentially leading to a no-start condition.

To solve this issue, ECS has engineered an exact-fit, upgraded ground strap for your BMW! Unlike its OEM counterpart, this design features insulated, large-gauge copper wire for dependable conductivity and long-lasting durability. Additionally, factory-style lugs are zinc-coated, crimped, and soldered, ensuring protection against corrosion and oxidation.

Whether you're replacing a visibly corroded strap or proactively preventing failure, this solution from ECS is sure to provide lasting performance and protection.

FEATURES

Direct-fit replacement and upgrade for E30 (318i/is), E36, E39, E46, and others Solves intermittent grounding issues caused by aging OEM straps Clean, stealthy design that fits seamlessly in factory engine bays Factory length and lug orientation for drop-in fitment 2 AWG tinned copper cable for excellent conductivity and corrosion resistance Zinc-coated lugs, crimped and soldered to resist moisture and oxidation Black UL1015-grade insulation withstands oil, heat, and abrasion Discreet ECS label for a clean, OEM+ look Replaces OEM part numbers 12421737755 and 12421714262.

The camshaft position sensor is essential for assisting the engine DME by monitoring the camshaft's position. The data from this sensor is key to optimizing ignition timing and ensuring smooth engine performance.

Often referred to as the CMP sensor, this component is crucial for the overall functionality of the powertrain. A failing camshaft position sensor can cause a range of issues, including engine stumbling, hesitation during acceleration, power loss, and even starting difficulties or complete failure to start.

Features & Benefits:

Two configurable linear 0-5V analog outputs Ability to calibrate O2 sensors for maximum accuracy Includes LC-2 controller and Bosch wideband O2 sensor Comes with a program cable, manual, and a 10 ft. sensor cable Includes a 1-inch mild steel exhaust bung Innovate MTS serial in/out capability Integrated dual-color status LED (green/red) Patented DirectDigital™ wideband sensor control Positive lock connectors for all connections Real-time display data on screen or with the powerful LogWorks software Range:

AFR (Air-Fuel Ratio) range from 7.4:1 to 22.4:1 (0.5 to 1.5 lambda)

Includes connector housing with terminals and seals. Commonly used for the crankshaft position sensor.

ECS Tuning replacement harness connectors include all necessary pins and wire seals for a complete harness repair. Whether you have a broken harness connector or need a complete wiring repair, we have the components you need.

Each connector includes an additional terminal in case one becomes lost or damaged during installation.

*OEM cross reference PN# 12521433916 - Commonly used for the crankshaft position sensor.

Please reference the original part number from the existing connector to confirm fitment, before ordering.

Suggested tools:

Suggested crimping pliers: T#387193
Wire De-pin tools:
12pc De-Pin Tool Set - T#386379
23pc De-Pin Tool Set - T#641943
