BMW Suspension Parts for BMW 4 Series F32 (2014+)

The ECS Coilover Line was designed with the "daily drivers" in mind! Focused on improving the performance and aesthetics of your vehicle without forgetting comfort. With 32 levels of available damping and height adjustments tailored to each car, ECS coilovers are right in that sweet spot of firm and compliant while giving you an aggressive look and vastly improved handling.

The ECS Tuning Performance Coilover System provides a sport-tuned, height, damping, and body adjustable suspension with substantial performance benefits using high-quality materials and coatings to replace your worn suspension, all while giving your vehicle that perfect ride height!

PERFORMANCE FEATURES:

32 levels of rebound damping adjustment
Includes adjustable front sway bar end links
Integrated camber plates for +/-1.5 degrees of adjustment to dial in your fitment and alignment
Lowering Adjustment of: 1.5" - 4"
Heat treated, progressive rate coil springs. 8k Front 10K Rear
Adjustable damping, monotube shocks/struts paired with optimized progressive rate coil springs gives your vehicle road-sticking grip with reduced body roll for exceptional confidence in your vehicle's handling. With your vehicle's new, lower ride height the center of gravity is now moved lower, further improving handling performance
Adjustable front bodies allow you to set the ride height while maintaining correct spring pre-load
Adjustable front and rear bodies allow the shock to operate in the correct valving range, regardless of ride height

PRODUCT DESIGN:

Strut and shock bodies finished with a durable gloss black powder coat for good looks and great longevity
Threaded portions are are zinc-coated for optimum corrosion protection against rain and salt (finish will vary between clear or black zinc coatings depending on availability)
Coil springs are powder-coated Reflex Silver Metallic finish for durability
Red anodized, billet aluminum spring seats with locking collars allow for quick, on the car, adjustability with the included spanner wrenches
Self-locking, zinc-coated flanged nuts used for shock & strut shaft pins
Anodized adjustable sway bar end links with heavy duty bushings
Zinc coated strut mount securing nuts included
Rear shock adjuster housings are black E-coated for durability
Zinc-coated lower spring perches
Integrated bump stops and dust boots

PRODUCT DEVELOPMENT

ECS Tuning Adjustable Damping Coilover Systems are developed in-house, tested and inspected by the Research & Development team in our Wadsworth, Ohio facility. The highest level of precision and quality through leading-edge product development technology and methods, ensuring the necessary long term product testing was performed on multiple test vehicles in the harshest conditions available.
Fitment:
For vehicles with 5 bolt upper strut mounts

F22, F23, F30, F32, F33, F34, F36

The ECS BMW Coilover line was designed with daily drivers in mind! The ECS engineer's focus was to improve the performance and look of the suspension, without forgoing ride comfort. Like many top-tier coilovers, these coilovers feel as smooth and comfortable as a stock setup, while also providing an aggressive look and vastly improved handling.

The ECS Performance Coilover System provides a sport-tuned, height, damping, and body adjustable suspension with substantial performance benefits using high-quality materials and coatings to replace your worn suspension, all while giving your vehicle that perfect ride height!

Spring Rates: 8kg/mm (front), 12kg/mm (rear)

PERFORMANCE FEATURES

32 levels of rebound damping adjustment Adjustable damping, monotube shocks/struts paired with optimized progressive rate coil springs give your vehicle road-sticking grip with reduced body roll for exceptional confidence in your vehicle's handling. With your vehicle's new, lower ride height the center of gravity is now moved lower, further improving handling performance Adjustable front bodies allow you to set the ride height while maintaining correct spring pre-load Adjustable front and rear bodies allow the shock to operate in the correct valving range, regardless of ride height PRODUCT DESIGN

Strut and shock bodies finished with a durable gloss black powder coat for good looks and great longevity Threaded portions are clear zinc-coated for optimum corrosion protection against rain and salt Coil springs are powder-coated Reflex Silver Metallic finish for durability Red anodized, billet aluminum lower spring seats with locking collars allow for quick, on-the-car, adjustability with the included spanner wrenches Integrated bump stops KIT CONTENTS

ECS Performance Adjustable Coilover System - F2X/F3X (3-Bolt) Front Suspension Installation Hardware Strut Mount Gasket - 31306868240 (2) Spindle Pinch Bolt - 31306798530 (2) Spindle Pinch Nut - 07119905032 (2) Tension Strut Bolt - 31106885777 (2) Control Arm Bolt - 31106797237 (2) Control Arm Nut - 33326760668 (2) Ball Joint Locking Nut - 33306787062 (4) Rear Suspension Installation Hardware Shock to Control Arm Bolt - 07119907372 (2) Shock to Control Arm Nut - 33326760668 (2) Shock Mount Bolt - 07119907137 (6) Shock Mount Gasket - 33506866038 (2) Control Arm to Wheel Carrier Bolt - 33326762875 (2) Control Arm to Wheel Carrier Nut - 33306760349 (2)

Introducing the all-new BMW Coilover line, meticulously crafted with daily drivers in mind. This line focuses on enhancing suspension performance and aesthetics without compromising comfort. Offering a smooth, stock-like feel, these coilovers provide an aggressive look and significantly improved handling at an unbeatable price.

Key Features:

• ECS Tuning Performance Coilover System:
  • Sport-tuned, height, damping, and body adjustable suspension
  • 32 levels of rebound damping adjustment
  • Optimized progressive rate coil springs with adjustable damping monotube shocks/struts
  • Lower ride height for improved handling with reduced body roll
  • Adjustable front bodies for personalized ride height and correct spring pre-load
  • Durable gloss black powder-coated strut and shock bodies
  • Clear zinc-coated threaded portions for corrosion protection
  • Powder-coated Reflex Silver Metallic finish on coil springs
  • Red anodized, billet aluminum lower spring seats with locking collars
  • Integrated bump stops for added durability

Turner Motorsport Upgraded Thrust Arm With Pre-installed Monoball Bushings:

Addressing the common issues of weak front thrust arm bushings in BMWs, this upgrade ensures optimal handling, braking performance, and an enhanced driving experience.

Features:

• Ball Joint / Monoball:
  • OEM BMW sealed, greased ball joint for exceptional durability
• Housing:
  • 6061-T6 anodized housing for excellent corrosion resistance
  • Proprietary Turner designed knurled OD for a perfect fit among different thrust arm bore diameters
• Bearing Inserts:
  • CNC machined 304ss for a precision fit between the ball joint and the subframe
• Performance:
  • Nearly instantaneous, crisp steering and braking response
  • Maintenance-free, long-lasting performance
  • Improved road feel without undesirable NVH

Upgrade your driving experience with these essential enhancements suitable for both street and track enthusiasts.

Our renowned TMS adjustable front sway bar / swaybar links for BMWs are now available in custom lengths, making them easy to order for any aftermarket or custom suspension setups. Simply measure for your ideal link length, and order the links with the best length range (below). Each sway bar link has a 10mm diameter mounting pin/stud, which is the typical factory/stock size for a universal fitment. These are sold by the pair, and each set includes two matching sway bar end links.

These end links offer the quiet operation and long life of "stock" BMW end links, but with the strength and adjustability of rod-end style sway bar links. These sway bar links can be used on a wide variety of BMWs and aftermarket BMW suspensions. When measuring, please consider that the length ranges of our Custom Adjustable end links are measured from the center to center on the end link mounting stud / pin, as shown in our diagram.

Note for E9X M3: the unique mounting on the M3 strut requires a set of our adapter seats (#TSU9912AF9). You can add them with your links from the menu below.


TMS Part#Center to Center (mm)Center to Center (inch)

TSU9912A35155.00mm - 170.00mm6.10" - 6.69"

TSU9912A40170.00mm - 185.00mm6.69" - 7.28"

TSU9912A45180.00mm - 195.00mm7.08" - 7.67"

TSU9912A50190.00mm - 205.00mm7.48" - 8.07"

TSU9912A55207.00mm - 222.00mm8.15" - 8.74"

TSU9912AF1220.00mm - 235.00mm8.66" - 9.25"

TSU9912A70240.00mm - 255.00mm9.45" - 10.04"

TSU4612AF3250.00mm - 265.00mm9.84" - 10.43"

TSU9912A80261.00mm - 276.00mm10.28" - 10.87"

TSU5012AF8280.00mm - 295.00mm11.02" - 11.61"

TSU9912A95290.00mm - 305.00mm11.42" - 12.00"

TSU9912110320.00mm - 335.00mm12.59" - 13.19"

TSU9912115330.00mm - 345.00mm12.99" - 13.58"

TSU9912130362.00mm - 377.00mm14.25" - 14.84"

TSU9912135370.00mm - 385.00mm14.57" - 15.16"

TSU9912140381.00mm - 396.00mm15.00" - 15.60"

TSU9912145389.00mm - 404.00mm15.31" - 15.91"

Please select your length below.

BMW’s are known to have failure prone front thrust arm bushings.  The flexible rubber bushings, even those found in M performance models, allow significant movement of the front wheels to maximize daily driving comfort, but also allow considerable alignment change.  This results in a disconnected and numb road feel, standing between you and a confidence inspiring driving experience.  Eventually the fluid filled rubber bushings fatigue and crack due to continual deflection and ozone degradation, and eventually the damping fluid leaks out resulting in complete failure.

For the enthusiast looking for superior performance and longevity with a crisp, confidence-inspiring driving experience, our sealed ball joint monoballs are the best solution available!  Our experience with spherical front control arm ball joints go back to those we designed and used in our IMSA E90 328i and E92 M3 racecars (GS class Champions in 2011).  We wanted to offer E31, E32, E34, E38, E39, E53, E60, E63, E64, and E83 owners similar levels of handling precision and control for the track and street.

The bearing housing is precision CNC machined from 6061-T6 anodized aluminum and features a knurled OD to ensure a perfect press fit, and utilize a sealed OEM BMW ball joint for exceptional quality and durability, making them completely at home on both the street and track with no compromise.  We have done extensive street, autocross, and track testing to ensure the ball joint used in this bushing design excels in each setting.  The advantage of a sealed ball joint is that it eliminates all unwanted deflection while still allowing complete bind-free movement throughout suspension travel, resulting in exceptional control of wheel alignment.  What you get is superior steering precision, turn-in response, direct braking feedback, and better handling.

In short, if you're seeking the ultimate in precise, predictable handling and control, with crisp braking response and a long service life that’s equally at home on the street or track - look no further. We have you covered.

Features:

Bearing housing

• Precision CNC machined from 6061-T6 blue anodized aluminum
• Knurled OD to provide the perfect fit for the wide range of thrust arm bore diameters among brands.
• CNC machined 304ss ball joint sleeve inserts, providing a precision fit between the ball joint and the subframe.

Bearing

• OEM BMW sealed and greased ball joint for exceptional durability and service life.

Performance

• Nearly instantaneous, crisp steering and braking response.
• Maintenance free, long lasting performance.
• Improved road feel without undesirable NVH.

Since BMW recommends the control arms be replaced for every other bushing change, we prefer to sell these as a pre-assembled set, and are available separately here if you would prefer that option.

This item is an upgrade to the following rear wheel drive BMWs:
2014+ F22 BMW 228i 230i M235i M240i - Coupe
2014+ F23 BMW 228i 230i M235i M240i - Convertible
2012+ F30 BMW 320i 328i 328d 335i 340i - Sedan
2014+ F32 BMW 428i 435i 440i - Coupe
2014+ F33 BMW 428i 435i 440i - Convertible
2014+ F36 BMW 428i 435i 440i - Gran Coupe

Fine-tuning your coilover damping shouldn’t mean stripping out your rear seats or interior panels. On many applications, rear shock adjusters are hidden behind carpet, trim, or seatbacks, making quick adjustments a hassle.

The ECS Rear Damping Extension Kit solves that problem with a clean and functional solution. These flexible extensions relocate the adjustment knobs to an easily accessible point above the rear shock towers, letting you dial in your suspension from inside the cabin, no disassembly required.

Installation is straightforward: simply drill a small access hole in your interior trim and route the extension cables through. The adjustment knobs can be removed to allow the line to pass through smaller openings, minimizing cutting. For proper installation, be sure to fully loosen the set screw, insert the cable, then securely tighten it using the provided Allen key.

Kit Includes:

(2) Rear damping adjuster extension cables

Installation hardware and Allen key

A smart upgrade for track cars, daily drivers, or anyone who values easy access to suspension tuning, without compromising interior fit and finish.

Receive up to a $70 rebate on Koni purchases through 5/31/2018! See documents tab below.

KONl Sport struts and shocks are the industry leader for user adjustable damping for daily drivers to weekend warriors. KONl Sport's familiar yellow color has for decades meant superior motion control and adjustability for the discerning driving enthusiast.


• Big handling improvements
• Reasonable ride quality
• Re-buildable for custom vehicle setups
• Best KONl shock for all lowering springs
• Lifetime Warranty

Activate your Koni Rebate!

•
• This item fits the following BMWs:
  2014+ F22 BMW 228i M235i
  2012+ F30 BMW 320i 328d 328i 335i - Sedan
  2013+ F32 BMW 428i 435i - Coupe
  Not for cars with Electronic Damping Control (EDC)

Is your BMW's suspension feeling loose and imprecise? It might be time for a refresh, and the team at Turner Motorsport has just the solution. Our front control arm refresh kit bundles all the essential components you need to restore your vehicle's handling and ride quality.

Why choose our kit? Because we understand the wear and tear that your BMW endures over time. Rough roads and harsh conditions take a toll on your suspension. With our comprehensive kit, you can address the common wear points in one go, ensuring optimal performance and longevity.

What's included in our kit? Everything you need: control arms, bushings, hardware, and more. By replacing these components together, you eliminate the risk of new parts being compromised by old, worn ones. Don't let sloppy handling and vague steering ruin your driving experience. Trust Turner Motorsport to provide a complete solution that restores the precision and feel of your BMW's suspension.

Signs that your front control arms may need replacing:

Clunking noise over rough roads Vague steering, especially at highway speeds Irregular tire wear Popping noises when going over bumps Vehicle pulling to one side during hard braking Don't wait for these symptoms to worsen. Upgrade your BMW's suspension with this front control arm refresh kit today.

KONl Sport struts and shocks are the industry leader for user adjustable damping for daily drivers to weekend warriors. KONl Sport's familiar yellow color has for decades meant superior motion control and adjustability for the discerning driving enthusiast.

• Big handling improvements
• Reasonable ride quality
• Re-buildable for custom vehicle setups
• Best KONl shock for all lowering springs
• Lifetime Warranty


Activate your Koni Rebate!

This item fits the following BMWs:
2014+ F22 BMW 228i M235i
2012+ F30 BMW 320i 328d 328i 335i - Sedan
2013+ F32 BMW 428i 435i - Coupe
Not for cars with Electronic Damping Control (EDC)
