Cat Cams Cat Cams M52B28 Sport Camshaft Set 1304212

Cat Cams M52B28 Sport Camshaft Set

Upgrade your M52B28 Engine with Cat Cams, a leader in the performance-aftermarket camshaft industry. These Camshafts will increase airflow into the engine by increasing the overall lift and duration over the factory cams. With their Sport cam setup, you can run all factory valvetrain, with no valve spring upgrades necessary! The VANOS (VVT) system on the intake camshaft changes the valve timing: M52 /B28: from 115° to 90° (exhaust: 105° fix) The data are shown for full intake retard (disengaged VVT). Check the distance between valves and piston to be 1mm at least with VVT engaged. Wrong installation will cause severe engine damage! Duration Intake @ .1mm: 250° Exhaust @ .1mm: 250° Intake @ 1mm: 213° Exhaust @ 1mm: 213° Lift Intake: 9.55mm Exhaust: 9.55mm Lobe Angle Intake: 110° Exhaust: 105°
Cat Cams Cat Cams
T#: 25805790 | Part#: 1304212
affirm Starting At 0% APR - Subject To Eligibility. See Lending Terms
Checking Vehicle Fitment...

Please ensure your correct model is selected

Does NOT fit your Change Vehicle

Fits your Change Vehicle

Change Vehicle

1524.99 $1524.99
Free Shipping on orders $49 and up
Availability:
Special Order
Est. Ship Date:
No Guaranteed ETA
Qty
Add to Wish List
Facebook Twitter Pinterest Google+ Email Price Alert
Cat Cams Cat Cams M52B28 Sport Camshaft Set 1304212
Cat Cams M52B28 Sport Camshaft Set
$1524.99

Upgrade your M52B28 Engine with Cat Cams, a leader in the performance-aftermarket camshaft industry. These Camshafts will increase airflow into the engine by increasing the overall lift and duration over the factory cams. With their Sport cam setup, you can run all factory valvetrain, with no valve spring upgrades necessary!
The VANOS (VVT) system on the intake camshaft changes the valve timing:

M52 /B28: from 115° to 90° (exhaust: 105° fix)

The data are shown for full intake retard (disengaged VVT). Check the distance between valves and piston to be 1mm at least with VVT engaged. Wrong installation will cause severe engine damage!

Duration
Intake @ .1mm: 250°
Exhaust @ .1mm: 250°
Intake @ 1mm: 213°
Exhaust @ 1mm: 213°

Lift
Intake: 9.55mm
Exhaust: 9.55mm

Lobe Angle
Intake: 110°
Exhaust: 105°

Prop 65 WarningProp 65 Warning

Cross Reference
  • 1304212/S

Product Q&A

Lifetime Replacement

This product is not eligible for Lifetime Replacement
MAKE MODEL SUBMODEL ENGINE Special Fitment Notes
BMW E36 328i M52 2.8L Use vehicle selector to confirm fitment
BMW E36 328ic M52 2.8L Use vehicle selector to confirm fitment
BMW E36 328is M52 2.8L Use vehicle selector to confirm fitment
BMW Z3 2.8 M52 2.8L Use vehicle selector to confirm fitment
